Control Ball Valve Series 46000

Ball valves are on/off flow control valves with a 90-degree rotation, used for regulating clean, contaminated, viscous, and corrosive liquid and gas media. The ball valves designed at Petro Sazeh Mihan are built to achieve optimal performance by adhering to the highest industry standards, with their sealing class reaching up to level (VI). One of the key features of these valves is their extensive rangeability.

Product Information

Separable Bonnet design availableStraight through flow pattern provides greater flow capacitiesThe unique self - aligning eccentric rotating plug provides tight shut off and low dynamic forces.A large variety of reduced trim options are available in all sizes

Size: 1 - 24 in

Class: 150 - 2500

Connection : Weld (Socket / Butt), Threaded, Flanged (RF / RTJ)

High CapacityHeavy DutyEnhanced flow capacitiesExcellent leakage controlSoft / Metal SeatReliable operationSimplified maintenanceBody Type : Cast with integral bonnetBody Material : Carbon steel / Stainless steelPlug Type : high capacity “V” contoured segmented ballFlow Characteristic : Equal percentageSpring-Opposed Diaphragm / Spring - Opposed Rolling Diaphragm Actuator
